PortaSinks - P350

PRODUCT MANUAL

Thank you for choosing the PortaSinks Self-Contained Portable Handwash Unit P350. This innovative station is designed to deliver hygienic handwashing wherever it is needed. With touch-free operation, rapid water heating, and a durable design, the PortaSinks offers reliable performance across a wide range of industries.

Our aim is to provide a simple, safe, and effective solution for maintaining high standards of hygiene at public events, workplaces, and healthcare settings.

Quality Assurance

Each PortaSinks Unit is factory-tested to ensure it meets safety and performance standards.


Every station undergoes checks for:
- Sensor responsiveness
- Water heating activation
- Leak-free plumbing connections
- Electrical safety compliance


This ensures your PortaSinks is safe, functional, and ready for immediate use.

PRODUCT OVERVIEW

The PortaSinks P350 is a self-contained, portable handwashing station that requires no permanent
plumbing. Built in compliance with Australian health and safety regulations, it delivers
convenience and reliability across a wide range of industries. This appliance is not intended
for use by persons (including children) with reduced physical, sensory, or mental capabilities,
or by those lacking experience and knowledge, unless they have been given supervision or
instruction regarding the use of the appliance by a person responsible for their safety.
Children must be supervised to ensure they do not play with the appliance

Key Features:

  • Touch-Free Operation

    Sensor-controlled water flow for improved hygiene.

  • Rapid Heating

    Warm water at 40–50 °C in under 2 seconds.

  • Water Efficient

    Up to 60 washes per 10 L fill (10 seconds per wash).

  • Integrated Soap Dispenser

    The integrated Soap Dispenser provides a complete handwashing solution.

  • Built-In Paper Towel Dispenser

    The P350's paper towel dispenser provides Immediate hand drying.

  • Durable Design

    Polymer body with stainless steel fittings for long service life

PortaSinks - P350

INSTALLATION INSTRUCTIONS

1. Unpacking

Carefully remove the PortaSinks unit from its packaging and inspect for any transport damage.

Ensure all included items are present:

  • PortaSinks Unit
  • Two 10L Water Containers
  • Power Cord
  • Soap Bottle
  • Paper Towel Dispenser (Pre-Installed)

2. Placement

  • Place the unit on a stable, level surface.
  • Ensure the station is positioned within reach of a 220–240V AC power outlet.

3. Water Container Setup

  • Place the clean water container on the right-hand side and fill with fresh water.
  • Place the wastewater container on the left-hand side.
  • Ensure both containers are secured correctly.

4. Power Connection

  • Plug the power cord into a suitable power outlet.

5. Soap & Paper Towels

  • Fill the soap bottle with liquid hand soap (Do not use foam soap)
  • Insert paper towels if required.

PortaSinks - P350

OPERATING INSTRUCTIONS

1. Power On

  • Switch the unit on using the power switch located at the upper-right of the door.
  • Heating will activate automatically.

2. Handwashing

  • Place hands under the sensor to activate water flow.
  • Warm water will dispense within approximately 2 seconds.

3. Use Soap & Towels

  • Dispense soap from the soap bottle
  • Wash hands under running water
  • Dry hands using paper towels

4. Refilling

  • Refill the clean water container on the right-hand side when required
  • Empty the wastewater container on the left-hand side when full

5. After Use / Storage

  • Switch off power if the unit will not be used for an extended period
  • Empty both water containers before storage

PortaSinks - P350

SAFETY INSTRUCTIONS

  • Always fill the clean water container before use
  • Do not immerse the station or expose electrical components to moisture
  • Disconnect from power before cleaning or servicing
  • Use fresh, clean water only — do not use chemicals or corrosive liquids
  • Keep the unit upright during use and transport
  • Do not operate if the unit is damaged or the power cord is frayed
  • Use only with properly rated power outlets
  • Do not use extension cords outdoors unless they are rated for outdoor use
  • Do not leave the station powered on and unattended for extended periods

PortaSinks - P350

MAINTENANCE & CARE

  • Refilling – Top up the clean water container and empty the wastewater container as needed
  • Cleaning – Wipe the exterior with mild soap and water. Avoid abrasive cleaners
  • Inspection – Regularly check the sensor, heating element, and plumbing connections
  • Consumables – Refill soap and paper towels frequently

PortaSinks - P350

TROUBLESHOOTING GUIDE

Problem A: Station Will Not Power On / No Sensor Light

  • Check that the station is plugged in
  • Ensure the power switch (upper right of the door) is turned on

Problem B: Station Powers On But No Water Flow

  • Refill the clean water container
  • Ensure the black pipe is correctly inserted into the clean water container

Problem C: Water Not Heating

  • Confirm the station is powered on
  • Ensure the water container is not empty
  • Contact service if the issue persists

Problem D: Sensor Not Detecting Hands

  • Wipe the sensor with a soft cloth
  • Avoid strong sunlight or reflective surfaces directly in front of the sensor

PortaSinks - P350

SPECIFICATIONS

Heating Temperature: 40–50°C (within 2 seconds)

Wash Capacity: Up to 60 × 10-second washes per 10L fill

Power Supply: 230V AC, 50Hz

Dimensions (H × W × D): 850mm × 350mm × 320mm

Weight: 9kg

Construction: Polymer body, stainless steel fittings

Operation: Sensor-controlled, automatic activation

Additional Features: Built-in soap dispenser, towel dispenser

PortaSinks - P350

COMPLIANCE INFORMATION

The PortaSinks Self-Contained Portable Handwash Unit is manufactured to meet relevant Australian safety and performance standards, including:

AS/NZS 60335.1 - Safety of Household and Similar Electrical Appliances

This compliance provides assurance that PortaSinks is designed and tested to operate safely under normal conditions of use.

Frequently Asked Questions

Does the PortaSinks P350 require plumbing?

No - the P350 is completely self-contained and does not require any connection to mains water or drainage. It’s designed to operate independently, making it ideal for spaces where plumbing isn’t available or practical.

How does the unit get power?


The P350 runs on a standard 240V power outlet. Simply plug it in and it’s ready to go - no special electrical setup required.

Does it provide hot water?

Yes - the unit delivers reliable hot running water on-demand, making it suitable for environments that require proper handwashing compliance.

How do you refill and empty the unit?

The system uses internal fresh and waste water tanks. Refilling and emptying is simple and can be done manually without tools, making day-to-day use easy and hassle-free.

What types of businesses is this suitable for?

The P350 is ideal for a wide range of industries including beauty salons, tattoo studios, medical rooms, construction sites, mobile services and temporary workspaces - anywhere compliant handwashing is required.

Is the unit easy to move around?

Yes - the unit is designed to be portable and can be repositioned as needed. It’s perfect for flexible setups or businesses that may need to relocate or reconfigure their space.

Is this unit compliant with hygiene regulations?


The P350 is designed to help businesses meet handwashing requirements where access to traditional plumbing isn’t available. We always recommend checking specific local regulations to ensure full compliance for your industry.
